Product Details
＋
[DESCRIPTION]
World smallest 45W charging hub. The upgraded GaN technology allows for a noticeably smaller design compared to the original stock components. In addition to protecting against overheating, overcurrent, voltage load, and short circuits, the 45W GaN charger is designed with preventive safety features.
Features
- Ultra-compact design, 60% smaller in size
- Uses GaN Technology for higher power efficiency and cooler operation
- Universal fast charge for Apple, Samsung, Huawei and Oppo, etc
- Support Power Delivery 45W and PPS 445W
- Works flawlessly with all mobile and tablets USB-C devices
- Charge 2 devices simultaneously
- Charge iPhone 8 and above with 50% power in 30 mins
- Higher power efficiency and cooler operation
- Over-voltage, over-current, short-circuitry and leakage protection
Design
- Input: AC 100-240V 50-60Hz 1.5A (Max)
- USB-C1/C2 Output: 5V=3A, 9V=3A, 12V=3A, 15V=3A, 20V=2.25A (PD 45W Max)
Programmable Power Supply: 3.3V-11V=4.05A (PPS45W) - Charging configurations:
C1 / C2 Output: PD45W
C1 C2 Output: PD20W PD20W - Total power: 45W
- 48 x 48 x 30.7mm
- 90g
[ENDDESCRIPTION]
[INFORMATION]
Power Delivery
iPhone 15 series | iPhone 14 series | iPhone 13 series | iPhone 12 series | iPhone SE | iPhone 11 series | XS | XS Max | XR | X | 8 Plus | 8 | iPad Pro 2018 | Samsung Galaxy S10 | S10 | S10e | Google Pixel 5 | Pixel 4a | Nexus 6P
[ENDINFORMATION]
[FAQ]
Can both ports support fast charging when use simultaneously?
Fast charging up to 20W is supported when both ports are in use. For 45W, you can only use one port at a time for the fast charging to work.
The charging speed slow when using both ports?
The total output will be adjusted to PD20W(USB-C1) 20W(USB-C2) when both ports are in use. Use only one port at a time to optimize it's 45W maximum charging capabilities.
[ENDFAQ]
